MEANS OF PRODUCTION – WORKSHOP

MEANS OF PRODUCTION – WORKSHOP

The company has its main site in Seclin. It owns the premises it occupies, which represent a workshop area of 6,000 m² on a site of more than 22,000 m².

• Maximum autonomous lifting capacity : 70 tons with 2 bridges of 35 tons, 1 bridge of 40 tons, 2 bridges of 8 tons, 2 semi gantries of 1.6 tons
• Dynamic bench balancer 2m, in pit 3.2m, lg 8m, load 6T. Associated Hoffman software
• Mechanical lathes for shafts or flanges with a maximum capacity of
  1,7 m – L : 4,5 m.
• Multifunctional tower with platform >2.4m – Lg 9m – load 20T, driven by electronic variator
• Winding lathes
• Main oven with effective dimensions : L * W * H 6.5m * 3m * 4m
• Secondary oven of effective dimensions : L * W * H 1.5m * 1.2m * 1.6m
• Unwinding oven with effective dimensions : 1.8m x 1.8m x 1.8m
• Manual unwinding stand

• Milling machines
• Shaft press 250 Tons
• Hydraulic puller for bearings and pulleys 50 tons, 700 bars
• Hydraulic power unit 3500 bars 4 outputs adjustable for the extraction of sleeves on smooth shaft ends
• Vacuum and pressure impregnation stand: effective height of the tank 3 m, effective diameter 2.5 m
• MEGGER MIT525 insulation testers and associated processing software
• MEGGER MIT1525 insulation tester and associated processing software
• Baker ST-2125 Shock Wave Tester
• Grognards and Prûfrex of induced controls
• Portable programmable three-phase generator for power network simulation and sources to be synchronized from CRE
• Surtronic Rugosimeter from TAYLOR-OBSON
• Vibration measuring device, spectral analysis, data collector type MOVILOG2 from STELL DIAGNOSTIC and associated OneProd XPR300 processing software
• Multivib global vibration measurement device.
• OPTALIGNE alignment device from PRUFTECHNICK and PC processing software
• PRUFTECHNICK ROTALIGNE lining machine and PC processing software
• TEKTRONIX digital memory oscilloscopes and processing software
• Generators and charging alternators
• Resistive load banks

• Programmable network analyzer MAP1000 from ENERDIS and PC processing software
• MAXEI type dielectric treatment equipment
• Centrifugal dielectric processing apparatus
• Transformer ratio measuring bridge
• Devices for the dielectric rigidity of windings
• Spintermeter dielectric rigidity 80Kv of transformer oils associated with its calibration bench.
• Mobile measuring equipment of Tangent Delta, 12Kv with compensation coil
• Mobile Partial Discharge measuring equipment, 12Kv with compensation choke
• Ohm’s law reduced deviation measuring equipment (variable DC voltage 500 – 15Kv)
• CHAUVIN ARNOUX Ray-Cam infrared camera and its operating and analysis software
• RIDGID SeaSnake Endoscope
• RIDGID Explorer endoscope with photo and video recording
• Endoscope and technical fibroscopy Bipol with photo and video recording Portable device for measuring very low resistances, micro-ohmmeter, 100A test type Megabrass MPK102
• Chauvin Arnoux portable winding resistance meter under 10A
